Description
| Metric | Specification | Practical Benefit |
| Drive System | Direct Drive Brushless DC Turbine | Delivers up to 350 m³/h volumetric flow with minimal water shear |
| Current Velocity | Variable up to 2.8 m/s | Accommodates athletic training regimes and serious fitness swimming |
| Power Efficiency | 45V DC Safe Low Voltage Operation | Reduces electricity consumption while delivering high water volume |
| Safety Standard | DIN EN 13451 / DIN EN 16582 | Full compliance with aquatic safety and suction anti-entrapment rules |
| Installation | Flush Recessed Wall Integration | Fits seamlessly into pool wall construction without intruding on swim space |
Engineered Power for Ambitious Swimmers
The EVAstream NEXT expands on turbine propulsion technology to deliver a substantially higher volumetric output. By moving water through a wider, deeper channel, this counter current system produces a continuous river-like flow that remains steady even at high resistance levels. Swimmers benefit from stable buoyancy without experiencing sudden water resistance breaks or uncomfortable facial spray.
Intuitive Speed Control and Interval Workouts
Advanced motor control allows micro-adjustments to current velocity directly from the pool. Swimmers can toggle between custom user profiles, switch training zones, or follow automated interval training programs. The gradual ramp-up feature ensures current speed transitions smoothly, keeping stroke cadence naturally balanced during high-intensity sessions.
Discreet Built-in Architecture
Engineered for flush wall niche installation, the NEXT model maintains clean pool geometry without compromising valuable interior space. Its silent underwater turbine housing is crafted from high-grade marine composites resistant to chemical degradation and salt chlorination, ensuring long-term durability in intensive residential and commercial settings.
Key Technical Specifications
-
Control Interfaces: Backlit underwater piezo push buttons, wall console, or mobile app
-
Lighting Option: Fully integrable with EVA Optic underwater LED lighting units
-
Power Supply: External control unit converting mains AC to safe 45V DC output
-
Submersible Rating: IPX8 certified waterproof drive housing
-
Pool Construction Types: Compatible with concrete, tiled, liner, panel, and stainless steel pools
Installation & Operating Guidelines
-
Niche Mounting: Embed the recessed mounting box flush into the pool wall structure during shell construction.
-
Conduit Routing: Pass low-voltage power supply cables through dedicated watertight conduit to the plant room control cabinet.
-
App Integration: Sync the digital controller to the local network to configure custom speed profiles and workout programs.
-
Underwater Operation: Adjust flow intensity directly from inside the pool using the illuminated piezo control switches.
Frequently Asked Questions
What is the difference between the EVAstream MOVE and NEXT models?
The NEXT model provides a higher flow output of up to 350 m³/h compared to the MOVE model (225 m³/h). This higher volume creates a stronger, deeper current designed specifically for advanced, fitness-focused, and competitive swimmers.
Can the EVAstream NEXT be fitted with underwater lighting?
Yes. The system can be integrated directly with EVA Optic underwater LED lights, allowing ambient lighting effects to illuminate the water current during night swims.
Is the EVAstream NEXT loud during high-speed operation?
No. Because the turbine drive sits fully submerged and moves water without high-pressure pumps or air injection, operating sound is suppressed naturally by the surrounding pool water.
What electrical setup is required for the plant room?
The system connects to standard single-phase or three-phase residential power supplies via an external transformer module, which steps down the voltage to a safe 45V DC before reaching the pool unit.
